Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding

Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding
Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding

Large Image :  Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding

Product Details:
Place of Origin: China
Brand Name: SHUOLONG
Certification: ISO9000, SGS, ect
Model Number: XY-M3412
Payment & Shipping Terms:
Minimum Order Quantity: 10m2
Packaging Details: Each pcs/roll packing by paper, 1-4 rolls/1-50pcs in a wooden box.
Delivery Time: 14-21 days
Payment Terms: T/T
Supply Ability: 2000m2 / month

Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding

Description
Product Name: Stainless Steel Architectural Mesh Material: SS304, SS316, SS316L
Rod Diameter: 4mm Rod Pitch: 120mm
Weight: 8.9kgs/m2 Opening Area: 64.5%
Mesh Thickness: 9.5mm Surface Treatment: Free Oil
Max Length: 100m Max Width: 6m
High Light:

ss316 architectural stainless steel mesh

,

facade cladding architectural stainless steel mesh

,

facade cladding stainless steel architectural mesh

SS316 Flexible Builing Wire Facade Cladding Mesh For Stainless Steel Architectural Mesh



Stainless Steel Architectural Mesh Information:



Stainless steel architectural mesh is made of stainless steel wire, carbon steel wire, etc., which acts on the surface of the building and plays the role of decoration, shading and energy saving. The stainless steel architectural mesh is woven with high-quality 304 or 316 stainless steel wire. The diameter wire is stainless steel wire rope, 2-4 wires are a group, and a group is set every certain distance. This distance and the thickness of the rope can be customized according to the requirements of the customer. The weft wire is a single stainless steel rod, and it is also one wire every certain distance, which is decided by the customer. The length direction is unlimited. It is the raw material of modern building metal decoration net.



Stainless steel architectural mesh is woven with metal rods and metal ropes, with good flatness on both sides and a strong three-dimensional sense. It is suitable for the decoration of building exterior walls, corridors, large office entertainment places, etc. it is a fashionable and beautiful decorative metal net with modern science and technology.



Stainless Steel Architectural Mesh Benefits:



Main features: it is non combustible, high-strength, strong, functional, easy to maintain, easy to form, extraordinary service life, and can protect building structures. It is more in line with the requirements of environmental protection and fire safety. Its installation is simple and fast, and it can be used in a large area or only used as local decoration. Its appearance is unique and elegant, and its decorative effects are vivid, strong and diverse. Its effects are different in different light, different environment, different time periods and different observation angles; It can be applied to a variety of occasions and uses. The unique texture of stainless steel and the matching effect of light highlight elegance, extraordinary personality and noble taste.



Stainless Steel Architectural Mesh data sheet:



Material Alu, SS304, SS316, Copper, ect Application Facade, Partitions, ect
Surface PVD, Paint, Antique Brass, ect Certificate ISO9000, SGS, ect
Weaving type Plain Woven Size Can be customized
Packing Wooden Case, Pallet, ect Color Can be customized

Stainless Steel Architectural Mesh Application:


The unique flexibility and gloss of Stainless steel architectural mesh is widely used in facades, partitions, ceilings and high-end interior and exterior decoration of museums, exhibition halls, cultural centers, stadiums, operas, high-end brand flagship stores, star rated hotels, cafes, shopping malls, villas, office buildings and other buildings. It can also be used as sunshade of buildings, balcony and corridor, column surface decoration, roller shutter, stair passage, and high-end interior decoration of hotels, offices, exhibition halls, stores, etc. The stainless steel decorative net is characterized by no limitation of space size, simple installation, and a very mysterious effect with light, which has a strong sense of modernity. It is beautiful in structure and durable. At the same time, it can also produce metal decorative nets with copper or aluminum alloy as raw materials. The finished products can be the original color of metal, and can also be painted into bronze, brass, red copper, jujube red or other colors. The height can be specially made according to needs.



Company Introduction:



Hebei ShuoLong Metal Products Co,. Ltd is an professional ISO certificated manufacturer of architectural metal mesh products. Since year 2008, ShuoLong team invest 6 technical engineers and designers in the research, development of innovation decorative metal mesh production.
Shuolong architectural &decorative wire mesh, cable mesh, pc mesh, spiral mesh, gabion baskets and fences, defensive barriers are popular in the interior & exterior decoration, wired laminated glass industry, landscaping and flood barrier and Military defense field.
Based on more than 12 years experience of worldwide big and small architectural metal mesh projects.



FAQ:



Q1.What is architectural mesh?
Produced from 80% recycled material, our wire mesh can be designed to fit virtually any architectural structure, inside or out. Because of the strength and aesthetic appeal of our stainless steel architectural mesh, it offers new and versatile fields of application in architecture.



Q2. What about the lead time?
A:We often ship in a few days from stock. Custom orders can normally be supplier in 1-2 weeks.



Q3. Do you have any MOQ limit for product order?
A: Low MOQ, 5 square meter for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.



Q5. How can get a specific quotation from us?
A: 1. let us know your requirements or application.
2. let us know the size(length & width) and quantity you need?
3. Please inform us of your company' name, address, Phone number and Email.
4.Please inform us of the shipping need by air or sea.
We quote according to your requirements or our suggestions.



Q6. PAYMENT
1. T/T 100% in advance. (Direct delivery, fast delivery)
2. T/T 30% as deposit, other 70% balance before shipment.(Need to wait until the final payment arrives, about 5 days will be delayed.


Shuolong Stainless Steel Architectural Mesh Products help you gain below advantages:

► Effective support from the design stage, timely samples.
► Quick response for price inquire and solution within 4 hours.
► A1 fire-proof material, help your project pass LEEDS easily.
► Available for stainless steel, aluminum, brass, copper, GI steel, Galfan, etc.
► Professional support in wire mesh install accessories solutions.
► Strictly QC system TO keep all products of good quality!
► More than 300 Chinese and foreign projects operation experience!
► Help you to save cost.

Packing:


The packing is very important of architectural mesh,the good packaging can effectively protect products to get the mesh to customer smmothly.
According different mesh types,sizes and characteristics, shuolong make good package for each other service center about your sourcng requirement.

Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding 0
Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding 1Ss316 Architectural Stainless Steel Mesh Flexible Builing Wire Facade Cladding 2
