Anticorrosion SS304 Architectural Mesh Screen Rigid Metal Mesh Facade

Anticorrosion SS304 Architectural Mesh Screen Rigid Metal Mesh Facade
Anticorrosion SS304 Architectural Mesh Screen Rigid Metal Mesh Facade Anticorrosion SS304 Architectural Mesh Screen Rigid Metal Mesh Facade Anticorrosion SS304 Architectural Mesh Screen Rigid Metal Mesh Facade Anticorrosion SS304 Architectural Mesh Screen Rigid Metal Mesh Facade

Large Image :  Anticorrosion SS304 Architectural Mesh Screen Rigid Metal Mesh Facade

Product Details:
Place of Origin: China
Brand Name: SHUOLONG
Certification: ISO9000, SGS, ect
Model Number: XY-1617
Payment & Shipping Terms:
Minimum Order Quantity: 10m2
Packaging Details: Each pcs packing by paper, 1-50pcs in a wooden box.
Delivery Time: 14-21 days
Payment Terms: T/T
Supply Ability: 2000m2 / month

Anticorrosion SS304 Architectural Mesh Screen Rigid Metal Mesh Facade

Description
Product Name: Woven Wire Mesh Panels Material: Stainless Steel
Weight: 11.8kg/m2 Opening Area: 9.5%
Mesh Thickness: 3mm Application: Decorative Mesh Screens
Color: Natural Color Surface Treatment: Free Oil
Max Width: 1.5m Max Length: 3m
High Light:

antiCorrosion Architectural Mesh Screen

,

SS304 Architectural Mesh Screen

,

Rigid metal mesh Facade

Rigid SS304 Architectural Mesh For Woven Wire Mesh Panels





Woven Wire Mesh Panels Information:



Woven wire mesh panels is woven with high-quality aluminum alloy wire, copper wire, stainless steel wire, etc. the finished product can be the original color of metal, or spray into other colors such as bronze, ebony black and jujube red. The width and height can be determined at will. The product has the characteristics of solemnity, generosity and good three-dimensional effect. It is more attractive under the light. It is an ideal decorative material for modern hotels, restaurants, exhibition halls and so on.



Woven Wire Mesh Panels Data Sheet:



Name Woven Wire Mesh Panels Material Stainless Steel
Surface Free oil Certificate ISO9000, SGS, ect
Weight 11.8kgs/m2 Application Decoration Screen
Color Natural Color Packing Pallet
Max Length 3m Max Width 1.5m



Woven Wire Mesh Panels Selling Points:



1. Fireproof

2. Resistance to Corrosion

3. Durability

4. Environmentally Friendly

5. Easy to Clean



Woven Wire Mesh Panels Technology:



Individual lengths of wires are sent through a crimper to establish both warp wires (Long wires) and fill wires (Cross wires). The warp wires are individually positioned through the loom’s heddle frames. The heddle frames provide the movement that creates the “Shed” in which a cross wire will be inserted manually or automatically. Once the cross wire is in position, the loom’s sleigh will force it into the next available crimp pocket on the warp wires. Then, the heddle frames will reposition creating the “Over/Under” sequence.



Woven Wire Mesh Panels Package:



Each pcs packing by paper, 1-50pcs in a wooden box.
